600mm Diamond Road Saw Blade for Reinforced Concrete and Asphalt Cutting
1. Features of 600mm Diamond Road Saw Blade for Reinforced Concrete and Asphalt Cutting
1. 100% Laser welding technology.
2. Undercut Protection segments provide enhanced lifetime when cutting Abrasive Materials.
3. Fits to Petrol Cutters, Bench & Floor Saw Machines.
4. Narrow U or key slot give a wider segment and longer lifetime. Wider U slot prevent clogging.
5. Dry or wet cutting reinforced concrete, aggregate concrete, hot rolled asphalt, asphalt, asphalt over concrete&green concete.
6. Well exported to Taiwan, Australia, Hongkong, Poland, Singapore, Thailand, USA etc.
2. Specification of 600mm Diamond Road Saw Blade for Reinforced Concrete and Asphalt Cutting
Diameter:600mm
Segment thickness:4.4mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm, 60mm, 80mm or as your request
| Inch | Diameter | Segment length | Segment thickness | Segment height | Segment number |
| (mm) | (mm) | (mm) | (mm) | (nos) |
| 24" | 600 | 40 | 4.4 | 10 | 42 |
| 24" | 600 | 40 | 4.4 | 12 | 42 |
| 24" | 600 | 40 | 4.4 | 15 | 42 |
Other size floor saw blade we could do as following
| OD (mm) | Teeth specification | Hole(mm) |
| Length (mm) | Thickness (mm) | Height (mm) | Number |
| 350 | 40 | 3.2 | 2010/12/15 | 24 | 25.4 |
| 400 | 40 | 3.4 | 2010/12/15 | 28 | 25.4 |
| 500 | 40 | 4 | 2010/12/15 | 36 | 25.4 |
| 650 | 40 | 4.8/5.0 | 2010/12/15 | 42 | 25.4 |
| 750 | 40 | 4.8/5.0 | 2010/12/15 | 46 | 25.4 |
| 800 | 40 | 4.8/5.0 | 2010/12/15 | 46 | 25.4 |
| 900 | 40 | 4.8/5.0 | 2010/12/15 | 52 | 25.4 |
| 1200 | 40 | 4.8/5.0 | 2010/12/15 | 68 | 25.4 |
| 1500 | 40 | 4.8/5.0 | 2010/12/15 | 90 | 25.4 |
3. Packing and Shipping of 600mm Diamond Road Saw Blade for Reinforced Concrete and Asphalt Cutting
5pcs 600mm laser welded floor saw blades are packed in one plywood, gross weight per plywood is limited within 90kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
Steel disc type, can do with Key slot, Narrow slot, or Wide slot, we can do as your request.
4. Packing and Shipping of 600mm Diamond Road Saw Blade for Reinforced Concrete and Asphalt Cutting
5pcs 600mm laser welded floor saw blades are packed in one plywood, gross weight per plywood is limited within 170kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
5. Payment term
T/T, Irrevocable L/C at sight,PayPal, West Union, Credit Card, etc.
6. Client Feedback
7. Our Related Products
8. Certification
9. Our Exhibition
10. FAQ
Q: How to place order to your company?
1.Required Products Details: Tell us what is your demand? Which kind of products, size, specification, cutting or grinding or drilling materials? HP of machine? Quantity? Nearest airport and seaport? Then we will give you best offer.
2.Performa Invoice: Offer satisfied, and then confirms the delivery time, payment term, logo, quantity, etc. According to this information, we will do Performa Invoice. Customers do the payment.
3.Production Process: Arrange production, based on the contract and PI description and mutual communication, we will follow closely the full production process; keep you informed of till finished the products under the contract limited time. Take photo of the goods for your reference. We take completely file in the computer from the raw material to producing process details, package, shipping. Easy for us to check each order.
4.Delivery: Dispatch the goods to appointed airport or seaport, prepare all shipping documents to customers.
5.After-Sale Service: Track the goods, learn the products' performance.
6.Feedback: Customers feedback to Johnson about quality, service, give us suggestion for our better improvement.
More information about our products, welcome to visit our website www.johnsontoolscn.com and www.diamondsaw-blade.com, you will get more than you can see.
Laser welded saw blade is our advantage products. Which are well sold to five continents more than 70 countries, hope to have chance to cooperate with you!
